Key Features |
0-60 degree rotatable angle Sliding structure for easy installation Philips Xitaninum driver for 5 years wrranty |
Construction Features |
Turnable and sliding structure design White or silver paint finish 1500px &3000px basic unit for infinite connection Housing material: Aluminum + PC Surface monuting / suspension installation |
Application |
Replace fluorescent batten Factory, Warehouse, Supermarket, MTR station,Train station, Airport, etc |
Technical Features |
Input Voltage:Philips driver: AC200-240V 50/60Hz Toppo driver: AC90-277V/50-60Hz Operation Voltage: DC36-42V Total harmonic distortion: THD<15% Power Factor: PF>0.95 Color Index: Ra>80 Lumen maintenance @6000h: >80% Switching cycle before failure: 100,000 IP Rating: IP40 Life Span: 50,000 hours Warranty: 5 years Operation Temperature: -15°C~+50°C Storage Temperature: -25°C~+55°C |
![]() |
![]() |
![]() |
Why choose us? |
Toppo Lighting is one of the leading traditional tube fixture led fluorescent replacement? manufacturers and suppliers in China, which is equipped with a productive factory. Welcome to import the newest traditional tube fixture led fluorescent replacement? at competitive price with us. We can also offer you customized service. |
1.What’s your main product line is made ?
We mainly produce LED indoor lights (LED Panel light, led Tri-proof light, LED Batten light, LED tube,LED Ceiling light, LED Down light, LED Round Panel Light, LED 2D ceiling Light,LED Wall Pack )
2.Do you have the ability to do independent and development ?
Our engineer department have 15-20 people. We have the research and development capabilities. We also collect regularly each customer feedback. We have product improvement and new product development. We also hold monthly new product launches.
3.If i have a questions I want to know , how can i contact you ?
You can find our platform or directly through major inquiry and send email to contact us.
4.How long do LEDs last ?
LEDs are rated by manufacturers to operate under normal conditions or 50000 hours of continuous use. As LEDs get older, they tend to dim and fade but aren’t susceptible to blinking like incandescent.
5.LEDs are more expensive than other lighting options.why ?
LEDs can operate as standalone devices,but when grouped or clustered they require additional steps to operate properly. LEDs need proper components such as a circuits can be designed rapidly, but to ensure that they operate correctly and for long periods of time they require testing.
c | Symbol | 2ft/60cm/32w | 4ft/120cm/40w | 4ft/120cm/60W | 5ft/150cm/60W | |
Product Code | / | TP-BTW2D1-32-E0 | TP-BTWS4D1-40-E0 | TP-BTW4D1-60-E0 | TP-BTW5D1-60-E0 | |
Rated Power | W | 2x16W | 2x20W | 2x30W | 2x30W | |
LED Typ/Qty | SMD3825 | 2x108 | 2x132 | 2x180 | 2x180 | |
Luminous Flux | LM | typ.3850-4150 | typ.4800-5200 | typ.7200-7800 | typ.7200-7800 | |
Luminous Efficacy | LM/W | typ.120-130 | ||||
Color Index | Ra | Ra>80 | ||||
Color Temperature | CCT(K) | WW:3000K NW:4000K PW: 5000K CW:6000K | ||||
Lumen maintance | % | >80% | ||||
AC Input Voltage | V | AC100-277V | ||||
Power Factor | PF | PF>0.95 | ||||
Flicker-free | / | Yes | ||||
Switching Cycle before Failure | Times | 100000 | ||||
Life Span | Hours | 50000 hours | ||||
Warranty | Years | 5 years | ||||
Operation Temperature | ℃ | -15℃~+50℃ | ||||
Storage Temperature | ℃ | -25℃~+55℃ |
