Toppo T8 Tube G13 End Cap with Scale High Lumen 5 Years Warranty UL DLC FCC

Toppo T8 Tube G13 End Cap with Scale High Lumen 5 Years Warranty UL DLC FCC

Shenzhen TOPPO lighting UL DLC CUL T8 led tubes have 95-105lm/w or 120-130lm/w available.And have aluminum case,thermal conductive adhesive under PCB and heat emission hole on PCB for effective heat dissipation performance.
Chat Now

Product Details

Toppo UL AC100-277V Popular Toppo T8 Tube G13 End Cap With Scale High Lumen 5 years warranty UL DLC FCC

Toppo UL AC100-277V Popular Toppo T8 Tube G13 End Cap With Scale High Lumen 5 years warranty UL DLC FCC
  Toppo UL AC100-277V Popular Toppo T8 Tube G13 End Cap With Scale High Lumen 5 years warranty UL DLC FCC
            Key Features

                1. 95-105lm/w or 120-130 LM/W by latest LED technology
                2. High lumen SMD2835 as light source

            Construction Features
             Patent designed heatsink system
                 Various kind colorful cap ring
                 180 degree rotatable end cap with scale
                 Socket / Diameter: Rotatable G13 / D26mm
                 Housing Material: D aluminum shape + PC cover

            Application

                 Industrial Lighting: Factory, Warehouse, etc
                 Commercial Lighting: Office, Supermarket,Hotel, Exhibition hall,etc.
                 Public Lighting: Residence, Library, Hospitals,School, MTR station, Train station, Bus station,Airport, etc.

          Technical Features
       Input Voltage: AC90-277V 50/60Hz
                 Operation Voltage: DC36-42V
                 Total harmonic distortion: THD: <10%
                 Power Factor: PF>0.95
                 Color Index: Ra>80
                 Lumen maintenance @6000h: >80%
                 Switching cycle before failure: 100,000
                 IP Rating: IP20
                 Life Span: 50,000 hours
                 Warranty: 5 years
                 Operation Temperature: -15°C~+50°C
                 Storage Temperature: -25°C~+55°C


Toppo UL AC100-277V Popular Toppo T8 Tube G13 End Cap With Scale High Lumen 5 years warranty UL DLC FCC


Toppo UL AC100-277V Popular Toppo T8 Tube G13 End Cap With Scale High Lumen 5 years warranty UL DLC FCC

Toppo UL AC100-277V Popular Rotatable G13 Cap T8 Tube with Scale Easy Instalation Widely Applicated High Brightness  5 Years Warranty 50000 hours life span
Toppo UL AC100-277V Popular Toppo T8 Tube G13 End Cap With Scale High Lumen 5 years warranty UL DLC FCC
            Why choose us?

           Toppo Lighting is one of the leading traditional tube fixture led fluorescent replacement? manufacturers and suppliers in China, which is equipped with a productive factory. Welcome to import the newest traditional tube fixture led fluorescent replacement? at competitive price with us. We can also offer you customized service.

FAQ:

1.Warranty ?

3-5 years from the manufacturing date.

2.How about your packaging ?

Neutral box, customized box is welcomed.

3.how important is IP ?

   Classifies and rates the degree of protection provided against intrusion (body parts such as hands and fingers), dust, accident contact, and water by mechanical casing and electrical enclosures

Hot Tags: toppo t8 tube g13 end cap with scale high lumen 5 years warranty ul dlc fcc, suppliers China, manufacturers, factory, customized, price, newest, made in China
