<tdApplication
| Product Features |
> High energy efficient - up to 130 lm/w > Asymmetric honeycomb-reflector-optic for low glare applications > Rail system for compatibility to Bosch-Rexroth profile system (and others) > Standardized European AC and DC connectors (AC: GST18i3 / DC: M12) > Input power range: 200-240VAC / 12-36VDC > DC reverse polarity protection & Rear power cable entry > Perfectly suitable for industrial areas due to IP54 > CCT adjustable by switch > D-Mark tested for the use in paper production, wood processing etc. > No UV or IR and completely mercury free > L80/B10 @ 50.000h > 5 years warranty |
| Options |
> Input Voltage ·AC Version : AC200-240V ·DC Version : DC12-36V > Controls and Dimming ·Wattage Adjustable > Beam Angle : ·60x90° degree ·40x110° degree > Installation ·Surface or profile mounted ·Usable in conjunction with aluminum profile accessories ·Telescope arm installation |
> Modern assembly lines > Factory workspaces & work tables > Machines requiring IP54 lights |
Dimension |
Beam angle |
Asymmetric AC Version
| Order Code | Product Name | Length | Rated Power | Lumen Output | Lumen Efficiency | CCT | Color Index | Beam Angle | AC Input | Power Factor | Flicker Free |
WL01-20PTR- NSN1B-001 | Premium 300mm Asymmetric Honeycomb Nero Workbench | 300mm | 10-20W adjustable | Max. 2600LM | 130LM/W | WW: 3000K PW: 5000K Mixed: 4000K | Ra>80 | 60°x90° 90°x110° | AC 200-240V | >0.95 | Y |
WL02-30PTR- NSN1B-001 | Premium 600mm Asymmetric Honeycomb Nero Workbench | 600mm | 20-30W adjustable | Max. 3900LM | 130LM/W | WW: 3000K PW: 5000K Mixed: 4000K | Ra>80 | 60°x90° 90°x110° | AC 200-240V | >0.95 | Y |
WL03-50PTR- NSN1B-001 | Premium 900mm Asymmetric Honeycomb Nero Workbench | 900mm | 30-50W adjustable | Max. 6500LM | 130LM/W | WW: 3000K PW: 5000K Mixed: 4000K | Ra>80 | 60°x90° 90°x110° | AC 200-240V | >0.95 | Y |
