LED tube lights are among the most popular and versatile lighting solutions available today. They’re particularly well suited to applications and install environments where the goal is to achieve a flexible variety of modern, clean-looking indoor lighting in rooms and displays of all sizes. You' ll often find assemblies of larger LED tube lights being used to provide bright, even lighting across many types of wider or more open spaces. Common examples might include commercial displays, workshops and laboratories, kitchens, hallways, foyers, factory floors, gymnasiums, car parks, and any other communal, multipurpose or high traffic areas. |
| Features |
Product Features: > Special Design for G5 cap > Up to 60% energy savings > 50,000 hours life span > 5 years warranty Options: > Lumen efficacy: 95-105LM/W or 120-130LM/W > Cap Ring Color: Various color > PC cover: Clear OR Frosted > Pink color for meat Applications: > Industrial Lighting: Factory, Warehouse, etc > Commercial Lighting: Office, Super-market, Hotel, Exhibition hall, etc > Public Lighting: Residence, Library, Hosptial, School, MTR station, Bus station, Train station, Airport, etc |
Technical Features: > Input Voltage: AC90-277V 50/60Hz > Operation Voltage: DC36-42V > Total harmonic distortion: THD: <10% > Power Factor: PF>0.95 > Color Index: Ra>80 > Lumen maintenance @6000h: >80% > Switching cycle before failure: 100,000 > IP Rating: IP20 > Life Span: 50,000 hours > Warranty: 5 years > Operation Temperature: -15°C~+50°C > Storage Temperature: -25°C~+55°C |
Data Sheet
General Version: 95-105LM/W
| Order Code | Product Name | Rated Power | Lumen Output | Lumen Efficiency | Color Index | AC Input | Power Factor | Match |
T802-10GN1- DMN6B-001 | 60CM-10W General T8 Tube | 10W | 1000LM | 100LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T804-18GN1- DMN6B-001 | 120CM-18W General T8 Tube | 18W | 1800LM | 100LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T804-20GN1- DMN6B-001 | 120CM-20W General T8 Tube | 20W | 2000LM | 100LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T805-22GN1- DMN6B-001 | 150CM-22W General T8 Tube | 22W | 2200LM | 100LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T805-25GN1- DMN6B-001 | 150CM-25W General T8 Tube | 25W | 2500LM | 100LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T805-30GN1- DMN6B-001 | 150CM-30W General T8 Tube | 30W | 3000LM | 100LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
Permium Version: 120-130LM/W
| Order Code | Product Name | Rated Power | Lumen Output | Lumen Efficiency | Color Index | AC Input | Power Factor | Match |
T802-10PN1- DMN6B-001 | 60CM-10W Permium T8 Tube | 10W | 1200LM | 120LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T804-18PN1- DMN6B-001 | 120CM-18W Permium T8 Tube | 18W | 2150LM | 120LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T804-20PN1- DMN6B-001 | 120CM-20W Permium T8 Tube | 20W | 2400LM | 120LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T805-22PN1- DMN6B-001 | 150CM-22W Permium T8 Tube | 22W | 2650LM | 120LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T805-25PN1- DMN6B-001 | 150CM-25W Permium T8 Tube | 25W | 3000LM | 120LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
T805-30PN1- DMN6B-001 | 150CM-30W Permium T8 Tube | 30W | 3600LM | 120LM/W | Ra>80 | AC 100-277V | >0.95 | Inductive ballast |
